A long translucent tube shows every flow mark, because the material carries light through the wall. The tool is gated at one end with a controlled fill profile, and the perforated band doubles as a way to disguise the small variations that remain.
Energy Storage Housings
Cylindrical Energy Storage Housing with Perforated Band
A translucent cylindrical housing with a perforated texture band and a molded sensor opening.
- Cylindrical tube housing
- Single sensor opening
- Translucent clear
- Perforated texture band
Specification
| Product type | Injection-molded housing |
|---|---|
| Housing style | Cylindrical tube housing |
| Plug / port configuration | Single sensor opening |
| Color as shown | Translucent clear |
| Surface | Perforated texture band |
| Tooling | New tool, or transfer of an existing tool |
| Secondary operations | Automatic sprue cutting; pin insertion and riveting where required |
| Compliance | Parts produced to RoHS requirements |
Construction & features
- Cylindrical body with a perforated decorative band
- Translucent wall for level or status visibility
- Rounded end caps blended into the body
- Sensor opening molded with a fine lip
Dimensions, material grade, wall thickness and surface are produced to the customer drawing and BOM. Send your 2D/3D files and we will reply with a tooling and part-price quotation.
