The taper on a wedge body is a draft angle in disguise: if the angle is too small the part drags, and if it is too large the shape looks wrong. The taper is designed as a product feature and the tool needs no side action because of it.
PD & Fast-Charge Housings
Wedge-Shaped Fast-Charge Housing with Two Pins
A wedge body that narrows towards the plug end, with two pins and a fine textured surface.
- Two-piece wedge body
- Two pins at the narrow end
- Black
- Fine texture
Specification
| Product type | Injection-molded housing |
|---|---|
| Housing style | Two-piece wedge body |
| Plug / port configuration | Two pins at the narrow end |
| Color as shown | Black |
| Surface | Fine texture |
| Tooling | New tool, or transfer of an existing tool |
| Secondary operations | Automatic sprue cutting; pin insertion and riveting where required |
| Compliance | Parts produced to RoHS requirements |
Construction & features
- Wedge profile with a continuous taper
- Pins at the narrow end with a reinforced platform
- Texture carried across the taper without gloss variation
- Tool design avoids slides on the visible faces
Dimensions, material grade, wall thickness and surface are produced to the customer drawing and BOM. Send your 2D/3D files and we will reply with a tooling and part-price quotation.
Inquiry
Send an inquiry
Tell us the part, the housing style, the annual volume and the market you sell in. Attach drawings by email after you send this form, or reply to our confirmation.
